Home >> Products >> Barcode Scanner >> 2D barcode scanner >> BWHS25 2D WIRELESS HANDHELD BARCODE SCANNER 2.4G BLUETOOTH
Features | |
Sensor | CMOS 640*480 |
Light Source | White LED |
Aiming | Red LED |
Scan Angle | Skew±60°Pitch±60°Roll 360° |
Resolution | ≥5mil |
Print Contrast | ≥20% |
Decode Capacity | |
1D | UPC-A, UPC-E, EAN-8, EAN-13, MSI, ISSN, ISBN, Code 93, Code 11, Code 128, Codabar, Code 39, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, GS1 DataBar |
2D | PDF417, Micro PDF417, QR Code, Micro QR, Aztec, Data Matrix |
Decode Range（Typical） | |
Code39（5mil） | 30mm~60mm Barcode Size：25mm*10mm |
QR（15mil） | 30mm~130mm Barcode Size：8mm*8mm |
EAN-13（13mil） | 30mm~180mm Barcode Size：31mm*17mm |
Accessory | |
Data Cable | Wired Transmission,Charging |
Refraction | Support 2.4G/Bluetooth Wireless Transmission Product Options |
Brackets | Fixable Products, Optional Accessories |
Physical | |
Interface | USB |
Operating Voltage | 5 VDC±5% |
Operating Current（Typical） | 220mA（3.7 VDC） |
Operating Current（Max） | 250mA（3.7 VDC） |
Standby Current | 90mA（3.7 VDC） |
Idle Current | 40mA （3.7 VDC） |
Fixed Power Consumption(Typical) | 814mW（3.7 VDC） |
Dimension | 165(W)×67(D)×102(H)mm |
Color | Black |
Net Weight | 146g (without receiver and cables) |
Country Keyboards | Multi-Country Keyboards |
Indicator | LED, Beeper |
Wireless Performance | |
Communication Mode | Synchronised Upload Mode / Manual Batch Upload Mode |
Wireless Standard | 2.4G/Bluetooth |
Transmission Distance (open area) | ≥80 Metres (2.4G) ≥15 Metres (Bluetooth) |
Storage Capacity | ≥5000 Entries (20-byte Code128) |
Battery Capacity | 2000 mAh |
Battery Charging Time | ≤6 hours |
Continuous Working Time | ≥18 hours (6 sec/repeat) (2.4G upload mode) |
Environmental | |
Operating Temperature | 0℃ ~ 50℃ |
Storage Temperature | -20℃ ~ 70℃ |
Humidity | 5% ~ 95%（Non-condensing） |
Drop | Withstand 5 drops from 1 meter height to concrete. |
Sealing Level | IP52 |
ESD | EN61000-4-2，±15KV Air Charge, ±8KV Direct Charge |
PRODUCT DESCRIPTION
Features | |
Sensor | CMOS 640*480 |
Light Source | White LED |
Aiming | Red LED |
Scan Angle | Skew±60°Pitch±60°Roll 360° |
Resolution | ≥5mil |
Print Contrast | ≥20% |
Decode Capacity | |
1D | UPC-A, UPC-E, EAN-8, EAN-13, MSI, ISSN, ISBN, Code 93, Code 11, Code 128, Codabar, Code 39, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, GS1 DataBar |
2D | PDF417, Micro PDF417, QR Code, Micro QR, Aztec, Data Matrix |
Decode Range（Typical） | |
Code39（5mil） | 30mm~60mm Barcode Size：25mm*10mm |
QR（15mil） | 30mm~130mm Barcode Size：8mm*8mm |
EAN-13（13mil） | 30mm~180mm Barcode Size：31mm*17mm |
Accessory | |
Data Cable | Wired Transmission,Charging |
Refraction | Support 2.4G/Bluetooth Wireless Transmission Product Options |
Brackets | Fixable Products, Optional Accessories |
Physical | |
Interface | USB |
Operating Voltage | 5 VDC±5% |
Operating Current（Typical） | 220mA（3.7 VDC） |
Operating Current（Max） | 250mA（3.7 VDC） |
Standby Current | 90mA（3.7 VDC） |
Idle Current | 40mA （3.7 VDC） |
Fixed Power Consumption(Typical) | 814mW（3.7 VDC） |
Dimension | 165(W)×67(D)×102(H)mm |
Color | Black |
Net Weight | 146g (without receiver and cables) |
Country Keyboards | Multi-Country Keyboards |
Indicator | LED, Beeper |
Wireless Performance | |
Communication Mode | Synchronised Upload Mode / Manual Batch Upload Mode |
Wireless Standard | 2.4G/Bluetooth |
Transmission Distance (open area) | ≥80 Metres (2.4G) ≥15 Metres (Bluetooth) |
Storage Capacity | ≥5000 Entries (20-byte Code128) |
Battery Capacity | 2000 mAh |
Battery Charging Time | ≤6 hours |
Continuous Working Time | ≥18 hours (6 sec/repeat) (2.4G upload mode) |
Environmental | |
Operating Temperature | 0℃ ~ 50℃ |
Storage Temperature | -20℃ ~ 70℃ |
Humidity | 5% ~ 95%（Non-condensing） |
Drop | Withstand 5 drops from 1 meter height to concrete. |
Sealing Level | IP52 |
ESD | EN61000-4-2，±15KV Air Charge, ±8KV Direct Charge |
