Home >> Products >> Barcode Scanner >> 2D barcode scanner >> BWHS26 2D WIRESS 2.4G BLUETOOTH BARCODE SCANNER
Specification
Specification | Sensor | 960*640 CMOS | |||
Decode capacity |
1D | EAN-8、EAN-13、EAN-13 2 add-on、 EAN-13 5 add-on、ISSN、ISBN、UPC-A、UPC-E、Code 32、Code 39、Code 93、Code 128、 Codabar、Industrial 2 of 5、Interleaved 2 of 5、 Matrix 2 of 5、GS1-128、 GS1 DataBar（RSS14）、GS1 DataBar Limited、GS1 DataBar Expanded | |||
2D | PDF417、MicroQR、Data Matrix、QR code、Aztec | ||||
Scanned area | Barcode | Min | Max | ||
5mil code39 | 2cm | 11cm | |||
13mil UPC | 3cm | 29cm | |||
20 mil code39 | 7cm | 50cm | |||
20 mil QR Code | 2cm | 22cm | |||
System support | Android、Windows XP、7、8、10、Linux、MACOS、IOS | ||||
Scan patterns | Manual、Auto-induction | ||||
Keyboard support | Multi-Country Keyboards | ||||
Minimum recognition | Code 39 , 6.6mil | ||||
Scan type | Paper,thin film 1D,2D, Screen 1D, 2D | ||||
Motion Tolerance | 1.8m/S | ||||
Print contrast | 25% | ||||
Scan angel | Roll±360°，Pitch±60°，Skew±70° | ||||
Barcode output editor | Support add prefix and suffix | ||||
Wireless specification | Wireless technology | Bluetooth | |||
Transmission distance(open space) | 15m | ||||
Wireless transmission power | 20dBm | ||||
Wireless receiving power | 20dBm | ||||
Indicator light | Red light for power ，Blue light for decode successfully | ||||
Buzzer | Open reminder、decode successful reminder、uploading reminder | ||||
Key | Start and trigger scan | ||||
Program update | Support user-end update | ||||
Product size | 113mm* 82.5mm*163.7mm | ||||
Cable length | 150CM(±3CM) | ||||
Scan times | Charge one time use 16000times 1000times/1hour | ||||
Charging time | 4.5hours | ||||
Storage capacity | 120000pcs | ||||
Battery | 1200MAH | ||||
Transmission mode | USB、bluetooth | ||||
PRODUCT DESCRIPTION
Specification
Specification | Sensor | 960*640 CMOS | |||
Decode capacity |
1D | EAN-8、EAN-13、EAN-13 2 add-on、 EAN-13 5 add-on、ISSN、ISBN、UPC-A、UPC-E、Code 32、Code 39、Code 93、Code 128、 Codabar、Industrial 2 of 5、Interleaved 2 of 5、 Matrix 2 of 5、GS1-128、 GS1 DataBar（RSS14）、GS1 DataBar Limited、GS1 DataBar Expanded | |||
2D | PDF417、MicroQR、Data Matrix、QR code、Aztec | ||||
Scanned area | Barcode | Min | Max | ||
5mil code39 | 2cm | 11cm | |||
13mil UPC | 3cm | 29cm | |||
20 mil code39 | 7cm | 50cm | |||
20 mil QR Code | 2cm | 22cm | |||
System support | Android、Windows XP、7、8、10、Linux、MACOS、IOS | ||||
Scan patterns | Manual、Auto-induction | ||||
Keyboard support | Multi-Country Keyboards | ||||
Minimum recognition | Code 39 , 6.6mil | ||||
Scan type | Paper,thin film 1D,2D, Screen 1D, 2D | ||||
Motion Tolerance | 1.8m/S | ||||
Print contrast | 25% | ||||
Scan angel | Roll±360°，Pitch±60°，Skew±70° | ||||
Barcode output editor | Support add prefix and suffix | ||||
Wireless specification | Wireless technology | Bluetooth | |||
Transmission distance(open space) | 15m | ||||
Wireless transmission power | 20dBm | ||||
Wireless receiving power | 20dBm | ||||
Indicator light | Red light for power ，Blue light for decode successfully | ||||
Buzzer | Open reminder、decode successful reminder、uploading reminder | ||||
Key | Start and trigger scan | ||||
Program update | Support user-end update | ||||
Product size | 113mm* 82.5mm*163.7mm | ||||
Cable length | 150CM(±3CM) | ||||
Scan times | Charge one time use 16000times 1000times/1hour | ||||
Charging time | 4.5hours | ||||
Storage capacity | 120000pcs | ||||
Battery | 1200MAH | ||||
Transmission mode | USB、bluetooth | ||||
