Performance | Image Sensor | 1280*1080 Coms Sensor | |
Illumination | White LED | ||
Aiming | Red LED | ||
Decode Capacity | 2D | QR Code，Data Matrix etc.. | |
1D | Code 39，Code 93，Code 128，CodaBar，EAN8，EAN13，ITF25，ITF14，UPCA，UPCE etc. | ||
Minimum Resolution* | ≥3mil | ||
Typical Decode Range* | UPC-13 (13mil) | 60mm~ 400mm（Barcode Size：32mm*25mm） | |
Code39 (3mil) | 45mm~80mm（Barcode Size：25mm*10mm） | ||
DM (10mil) | 70mm~420mm（Barcode Size：45mm*220mm） | ||
Minimum Print Contrast* | ≥20% | ||
FOV | 40°（H） 34°（V） | ||
Development | Communication Protocol | Serial Protocol Command | |
Firmware Update | USB update | ||
Electrical | Interface | USB、RS-232、 | |
Dimension(mm) | 68(W)×96.5 (D)×175(H) | ||
Net Weight | 142g | ||
Voltage | 5 VDC±5% | ||
Power | 1500mW(Typical) | ||
Current@5 VDC | Operating | 280mA(RMS Typical) | |
Environmental | Operating Temperature | 0℃~+50℃ | |
Storage Temperature | -40℃~+70℃ | ||
Humidity | 5%~95%（Non-Condensing） | ||
Ambient Light | 0~100,000LUX | ||
Accessories | Cable Cord | USB | USB Cable |
RS-232 | RS-232 Cable and External Power Supply |
