Print Function | |||
Printing Mode | Line thermal printing | ||
Print Count | 576 points/line | ||
Dot Density | 8 o 'clock /mm | ||
Print Speed | Maximum print speed 120mm/s | ||
Print Width | 20-76mm | ||
Discharge Direction | Feed sheet | ||
Port | USB-B/Bluetooth wireless module | ||
Print Font | |||
Typeface | Font A：12 × 24 Font B：9 × 17 Chinese：24×24 | ||
Character Size | Font A：1.5×3.00mm Font B：1.13×2.13mm Chinese：3.00×3.00mm | ||
Character Per Line | Font A:32/ Font B:42/ Chinese:16 | ||
1D Barcode | UPC-A / UPC-E / JAN13 (EAN13) / JAN8 (EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 | ||
2D Barcode | QR Code, PDF 417 | ||
Paper Size | |||
Wide | 30~80mm | ||
Diameter | ≤135mm（MAX） | ||
| Label paper, folding paper, continuous paper | ||
Electrical Specification | |||
Power Supply Standard | Input：AC 110V/220V, 50～60Hz ; Output：DC 24V/1.5A | ||
Wireless Function | |||
Bluetooth Connection Distance | ≥15m（Open lot） | ||
Print Instruction | |||
Order | TSPL | ||
Appearance | |||
Size（mm） | 160(W)*110(D)*93(H)mm | ||
Weight (approximate weight) | 1.24kg（With accessories） | ||
Reliability | |||
Print head life | 50 km | ||
Sensor | 50 km or 108 pulse | ||
Operating Environment | |||
Operating Temperature (no condensation) | 0℃ ~ 50℃ | ||
Storage Temperature (no condensation) | ﹣20℃ ~ 60℃ (No paper) | ||
Operating Humidity (no condensation) | 20%RH ~ 85%RH | ||
Storage Humidity (no condensation) | 5％RH ~ 95％RH(No paper) | ||
PRODUCT DESCRIPTION
Print Function | |||
Printing Mode | Line thermal printing | ||
Print Count | 576 points/line | ||
Dot Density | 8 o 'clock /mm | ||
Print Speed | Maximum print speed 120mm/s | ||
Print Width | 20-76mm | ||
Discharge Direction | Feed sheet | ||
Port | USB-B/Bluetooth wireless module | ||
Print Font | |||
Typeface | Font A：12 × 24 Font B：9 × 17 Chinese：24×24 | ||
Character Size | Font A：1.5×3.00mm Font B：1.13×2.13mm Chinese：3.00×3.00mm | ||
Character Per Line | Font A:32/ Font B:42/ Chinese:16 | ||
1D Barcode | UPC-A / UPC-E / JAN13 (EAN13) / JAN8 (EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 | ||
2D Barcode | QR Code, PDF 417 | ||
Paper Size | |||
Wide | 30~80mm | ||
Diameter | ≤135mm（MAX） | ||
| Label paper, folding paper, continuous paper | ||
Electrical Specification | |||
Power Supply Standard | Input：AC 110V/220V, 50～60Hz ; Output：DC 24V/1.5A | ||
Wireless Function | |||
Bluetooth Connection Distance | ≥15m（Open lot） | ||
Print Instruction | |||
Order | TSPL | ||
Appearance | |||
Size（mm） | 160(W)*110(D)*93(H)mm | ||
Weight (approximate weight) | 1.24kg（With accessories） | ||
Reliability | |||
Print head life | 50 km | ||
Sensor | 50 km or 108 pulse | ||
Operating Environment | |||
Operating Temperature (no condensation) | 0℃ ~ 50℃ | ||
Storage Temperature (no condensation) | ﹣20℃ ~ 60℃ (No paper) | ||
Operating Humidity (no condensation) | 20%RH ~ 85%RH | ||
Storage Humidity (no condensation) | 5％RH ~ 95％RH(No paper) | ||
